High Precision Digital Inclinometer with ±30° Measurement Range and 0.001° Resolution for Industrial Angle Measurement

FMI815/825 is a digital display inclinometer for angle control and measurement in various industrial fields. The core of this product adopts micro-mechanical control principle and dual-core measurement unit. During measurement, the Y-axis compensates the X-axis, utilizing interleaving and temperature compensation model algorithms to maximize the operational advantages of micro-mechanical electronic principles. This ensures long-term stability and repeatability of instrument measurements.

Features ±30° measurement range, 0.001° resolution, accuracy of <0.005° full range, fast response, stable data, easy installation and use. This product includes data storage function, three measurement modes (angle, degree/minute/second, mm/m), powerful expandability, convenient practical application, industrial reliability, high cost performance, and competitive advantages in the international market.

• Measured accuracy: < 0.005°
• Angle resolution: 0.001°
• Filter frequency optional
• Measurement range: ±30°
• Absolute/relative measurement switching
• Data storage function
• Automatic angle interleaving compensation function
• Fixed installation measurement capability
• Working temperature: -10℃ ~ +70℃
• Angle/length double unit switching
• Night vision four-color screen
• Customer-calibratable zero point
• Alarm angle setting capability
• 3 measurement modes (angle, degree/minute/second, mm/m)

• Building construction
• Production fixture
• Vehicle four-wheel detection
• Mechanical installation
• Pipeline installation
• Industrial platform
• PTZ angle detection
• Turntable detection
• Medical instrument
• Road slope
